3.2V 100Ah Lithium Iron Phosphate Battery

All products >
Prismatic LFP Cell >
LF100LA

LF100LA

EVE LF100LA battery 3.2V lifepo4 100Ah cells 3.2v 100ah lifepo4 battery cell 100Ah lifepo4 battery lifepo4 100Ah battery lifepo4 cell 100Ah electric vehicles lithium ion battery energy storage

Model Name： LF100LA
Nominal Capacity： 102Ah
Nominal Voltage： 3.2V
Cycle Life： 5000 Cycles
Data Sources： EVE's Laboratory

Overview

Specification Parameters
Nominal Capicity	102Ah
Nominal Voltage	3.2V
Charging Temperature	0~65℃
Discharging Temperature	-20~65℃
Charging Cut-off Voltage	3.65V
Standard Charging/Discharging Current	0.2C/0.2C
Model Name	LF100LA
AC Impedance Resistance	≤0.5mΩ
Weight	1985±100g
Cycle Life	5000 Cycles
Terminal Height	118.5±0.5mm
Shoulder Height	115.7±0.5mm
Width	160.0±0.8mm
Thickness	50.1±0.5mm
